gefran GPC - Virtual Register Address Table

81901 “MSW_GPC-40/600A”_03-2021_ENG_page 124
3.34.5. Virtual register address table
Parameter bit Enabled resource
Single-node
address
Multi node
address
Format Register name
S.In_1
0 Alarm threshold AL1 for GPC-M 1365 341 word SERIAL_AL1_1
1 Alarm threshold AL2 for GPC-M 1366 342 word SERIAL_AL2_1
2 Alarm threshold AL3 for GPC-M 1367 343 word SERIAL_AL3_1
3 Alarm threshold AL4 for GPC-M 1345 321 word SERIAL_AL4_1
8 Input In.A3 1709 685 word SERIAL_ANALOG3
9 Input In.A2 1737 713 word SERIAL_ANALOG2
10 Input In.A1 4605 581 word SERIAL_ANALOG1
S.In_2
0 Alarm threshold AL1 for GPC-E1 2389 341 word SERIAL_AL1_2
1 Alarm threshold AL2 for GPC-E1 2390 342 word SERIAL_AL2_2
2 Alarm threshold AL3 for GPC-E1 2391 343 word SERIAL_AL3_2
3 Alarm threshold AL4 for GPC-E1 2369 321 word SERIAL_AL4_2
S.In_3
0 Alarm threshold AL1 for GPC-E2 4437 341 word SERIAL_AL1_3
1 Alarm threshold AL2 for GPC-E2 4438 342 word SERIAL_AL2_3
2 Alarm threshold AL3 for GPC-E2 4439 343 word SERIAL_AL3_3
3 Alarm threshold AL4 for GPC-E2 4417 321 word SERIAL_AL4_3
S.Ou
0 OUT 1 output 1368 344 word, bit 0 SERIAL_IN_OUT
1 OUT 2 output 1368 344 word, bit 1 SERIAL_IN_OUT
2 OUT 3 output 1368 344 word, bit 2 SERIAL_IN_OUT
4 OUT 5 output (relay) 1368 344 word, bit 4 SERIAL_IN_OUT
4 OUT 5 output (Analog A1) 1751 727 word SERIAL_OUTA1
5 OUT 6 output (relay) 1368 344 word, bit 5 SERIAL_IN_OUT
5 OUT 6 output (Analog A2) 1752 728 word SERIAL_OUTA2
6 OUT 7 output (relay) 1368 344 word, bit 6 SERIAL_IN_OUT
6 OUT 7 output (Analog A3) 1753 729 word SERIAL_OUTA3
7 OUT 8 output (relay) 1368 344 word, bit 7 SERIAL_IN_OUT
8 OUT 9 output 1368 344 word, bit 8 SERIAL_IN_OUT
9 OUT 10 output 1368 344 word, bit 9 SERIAL_IN_OUT
S.LI
0 LED RN 1375 351 word, bit 0 SERIAL_LED
1 LED ER 1375 351 word, bit 1 SERIAL_LED
2 LED D1 1375 351 word, bit 2 SERIAL_LED
3 LED D2 1375 351 word, bit 3 SERIAL_LED
4 LED O1 1375 351 word, bit 4 SERIAL_LED
5 LED O2 1375 351 word, bit 5 SERIAL_LED
6 LED O3 1375 351 word, bit 6 SERIAL_LED
7 LED BUT 1375 351 word, bit 7 SERIAL_LED
8 D1 input 1368 344 word, bit 10 SERIAL_LED
9 D2 input 1368 344 word, bit 11 SERIAL_LED
10 D3 input 1368 344 word, bit 12 SERIAL_LED
11 D4 input 1368 344 word, bit 13 SERIAL_LED
