3.14.14. HB alarm status (single-phase configuration or CT phase 1 two-phase or three-
phase configuration)
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1100
76 bit
BIT_
STATUS_
HB
M
MainMenu → M → Expert →
Bit → BIT_STATUS_HB_1
R2124 E1
MainMenu → E1 → Expert →
Bit → BIT_STATUS_HB_2
4172 E2
MainMenu → E2 → Expert →
Bit → BIT_STATUS_HB_3
The parameter shows the HB alarm status in the single-phase configuration or that of CT phase 1 in the two-phase or three-phase config-
uration.
Options: OFF = Alarm off
ON = Alarm on
3.14.15. HB alarm status (single-phase configuration or CT phase 2 two-phase or three-
phase configuration)
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1101 77 bit
BIT_
STATUS_
HB_
PHASE2
Global
MainMenu → M → Expert →
Bit → BIT_STATUS_HB_PHASE2_1
R
The parameter shows the HB alarm status in the single-phase configuration or that of CT phase 2 in the two-phase or three-phase config-
uration.
Options: OFF = Alarm off
ON = Alarm on
3.14.16. HB alarm status (single-phase configuration or CT phase 3 three-phase
configuration)
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1102 78 bit
BIT_
STATUS_
HB_
PHASE3
Global
MainMenu → M → Expert →
Bit → BIT_STATUS_HB_PHASE3_1
R
The parameter shows the HB alarm status in the single-phase configuration or that of CT phase 3 in the three-phase configuration.
Options: OFF = Alarm off
ON = Alarm on
