gefran GPC - Alarm Status Masks for Custom Output 9; Alarm Status Masks for Custom Output 10

81901A “MSW_GPC-40/600A”_03-2021_ENG_page 89
3.19.6. Alarm status masks for custom output 9
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1934 910 16 bit
OCM.9_1
Global
MainMenu → Global → Expert →
Output Custom → OCM.9_1
R/W
■
Unsigned
Short
4095
1935 911 16 bit
OCM.9_2
Global
MainMenu → Global → Expert →
Output Custom → OCM.9_2
R/W
■
Unsigned
Short
4095
1936 912 16 bit
OCM.9_3
Global
MainMenu → Global → Expert →
Output Custom → OCM.9_3
R/W
■
Unsigned
Short
4095
1937 913 16 bit
OCM.9_4
Global
MainMenu → Global → Expert →
Output Custom → OCM.9_4
R/W
■
Unsigned
Short
4088
1938 914 16 bit
OCM.9_5
Global
MainMenu → Global → Expert →
Output Custom → OCM.9_5
R/W
■
Unsigned
Short
4088
1939 915 16 bit
OCM.9_6
Global
MainMenu → Global → Expert →
Output Custom → OCM.9_6
R/W
■
Unsigned
Short
4088
1940 916 16 bit
OCM.9_7
Global
MainMenu → Global → Expert →
Output Custom → OCM.9_7
R/W
■
Unsigned
Short
26195
1941 917 16 bit
OCM.9_8
Global
MainMenu → Global → Expert →
Output Custom → OCM.9_8
R/W
■
Unsigned
Short
26195
1942 918 16 bit
OCM.9_9
Global
MainMenu → Global → Expert →
Output Custom → OCM.9_9
R/W
■
Unsigned
Short
26195
1943 919 16 bit
OCM.9_10
Global
MainMenu → Global → Expert →
Output Custom → OCM.9_10
R/W
■
Unsigned
Short
943
The parameters set the alarm status masks ALSTATE_IRQ, STATUS3, STATUS4, and VOLTAGE_STATUS for custom output OUT9.
min...max: 0...65535
3.19.7. Alarm status masks for custom output 10
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1944 920 16 bit
OCM.10_1
Global
MainMenu → Global → Expert →
Output Custom → OCM.10_1
R/W
■
Unsigned
Short
4095
1945 921 16 bit
OCM.10_2
Global
MainMenu → Global → Expert →
Output Custom → OCM.10_2
R/W
■
Unsigned
Short
4095
1946 922 16 bit
OCM.10_3
Global
MainMenu → Global → Expert →
Output Custom → OCM.10_3
R/W
■
Unsigned
Short
4095
1947 923 16 bit
OCM.10_4
Global
MainMenu → Global → Expert →
Output Custom → OCM.10_4
R/W
■
Unsigned
Short
4088
1948 924 16 bit
OCM.10_5
Global
MainMenu → Global → Expert →
Output Custom → OCM.10_5
R/W
■
Unsigned
Short
4088
1949 925 16 bit
OCM.10_6
Global
MainMenu → Global → Expert →
Output Custom → OCM.10_6
R/W
■
Unsigned
Short
4088
1950 926 16 bit
OCM.10_7
Global
MainMenu → Global → Expert →
Output Custom → OCM.10_7
R/W
■
Unsigned
Short
26195
1951 927 16 bit
OCM.10_8
Global
MainMenu → Global → Expert →
Output Custom → OCM.10_8
R/W
■
Unsigned
Short
26195
1952 928 16 bit
OCM.10_9
Global
MainMenu → Global → Expert →
Output Custom → OCM.10_9
R/W
■
Unsigned
Short
26195
1953 929 16 bit
OCM.10_10
Global
MainMenu → Global → Expert →
Output Custom → OCM.10_10
R/W
■
Unsigned
Short
943
The parameters set the alarm status masks STATUS3, STATUS4, ALSTATE_IRQ and VOLTAGE_STATUS for custom output OUT10.
min...max: 0...65535
