gefran GPC - Status (STATUS_W); Manual Power Correction; Mains Voltage

81901 “MSW_GPC-40/600A”_03-2021_ENG_page 102
3.22.3. Status (STATUS_W)
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1329
305 16 bit
07.02.14
STA-
TUS_W
M
MainMenu → M → Controls →
STATUS_W_1
R/W
■
Unsigned
Short
02353 07.03.14 E1
MainMenu → E1 → Controls →
STATUS_W_2
4401 01.04.14 E2
MainMenu → E2 → Controls →
STATUS_W_3
The parameter sets the Automatic/Manual and Software startup/shutdown operating status of the controller with bits.
Options:
bit Status setting
3 ON/OFF selection
4 AUTO/MAN selection
3.23. Manual power correction
In manual operation, the power output can be corrected
automatically in relation to the reference mains voltage (riF).
The% correction value (Cor) is freely adjustable and acts in
an inversely proportional manner, i.e., if the reference volt-
age increases, the power output decreases, and vice versa.
The function is switched on and off via the SP.r parameter.
In addition to the parameters explained below, the STA-
TUS_W parameter should also be considered in manual
power correction (see paragraph “3.22.3. Status (STA-
TUS_W)”.
When moving from AUTO to MAN mode, sudden output
changes are possible.
3.23.1. Mains voltage
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1529
505 16 bit
07.02.07
riF
M
MainMenu → M → Controls → riF_1
R/W
■
Float
(####.#)
V 0.02553 07.03.07 E1
MainMenu → M → Controls → riF_2
4601 01.04.07 E2
MainMenu → M → Controls → riF_3
The parameter sets the reference mains voltage, i.e., the voltage value against which the actual voltage is compared in order to keep the
output power constant.
min...max: 0.0...999.9
3.23.2. Manual power correction
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1530
506 16 bit
07.02.08
Cor
M
MainMenu → M → Controls → Cor_1
R/W
■
Float
(####.#)
% 0.02554 07.03.08 E1
MainMenu → E1 → Controls → Cor_2
4602 01.04.08 E2
MainMenu → E2 → Controls → Cor_3
The parameter sets the manual power correction depending on the mains voltage.
The maximum manual power correction is limited to ± 65%.
min...max: 0.0...100.0
