81901 “MSW_GPC-40/600A”_03-2021_ENG_page 76
3.15.12. NO_CURRENT alarm status (single-phase configuration or CT phase 1 two-phase
or three-phase configuration)
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1126
102 bit
BIT_
STATUS_
NO_CUR-
RENT
M
MainMenu → M → Expert →
Bit → BIT_STATUS_NO_CURRENT_1
R2150 E1
MainMenu → E1 → Expert →
Bit → BIT_STATUS_NO_CURRENT_2
4198 E2
MainMenu → E2 → Expert →
Bit → BIT_STATUS_NO_CURRENT_3
The bit shows the NO_CURRENT alarm status in single-phase configuration or the CT phase 1 status in two-phase or three-phase config-
uration.
Options: OFF = Alarm off
ON = Alarm on
3.15.13. NO_CURRENT alarm status (single-phase configuration or CT phase 2 two-phase
or three-phase configuration)
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1127 103 bit
BIT_
STATUS_
NO_CUR-
RENT_
PHASE2
M
MainMenu → M → Expert → Bit →
BIT_STATUS_NO_CURRENT_PHASE2_1
R
The bit shows the NO_CURRENT alarm status in single-phase configuration or the CT phase 2 status in two-phase or three-phase config-
uration.
Options: OFF = Alarm off
ON = Alarm on
3.15.14. NO_CURRENT alarm status (single-phase configuration or CT phase 3 three-phase
configuration)
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1128 104 bit
BIT_
STATUS_
NO_CUR-
RENT_
PHASE3
M
MainMenu → M → Expert → Bit →
BIT_STATUS_NO_CURRENT_PHASE3_1
R
The bit shows the NO_CURRENT alarm status in single-phase configuration or the CT phase 3 status in three-phase configuration.
Options: OFF = Alarm off
ON = Alarm on
