3.20.2. Analog output reference allocation
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1892 868 16 bit 06.05.02 rF.A01 Global
MainMenu → Global →
Outputs → Analog output1 → rF.A01
R/W
■
Unsigned
Short
0
1893 869 16 bit 06.06.02 rF.A02 Global
MainMenu → Global →
Outputs → Analog output2 → rF.A02
R/W
■
Unsigned
Short
0
1894 870 16 bit 06.07.02 rF.A03 Global
MainMenu → Global →
Outputs → Analog output3 → rF.A03
R/W
■
Unsigned
Short
0
The parameter sets the type of reference signal for analog outputs 1, 2 and 3, depending on the address used.
Each type of signal has a unit of measurement and a scale with minimum and maximum permissible limits. The limits used are specified
with the parameters LS.AOx and HS.AOx.
Allocation is identified by an index.
Options:
Index Type of reference signal
Scale limits
Unit of mea-
surement
Min Max
0 None - - -
1 Ou.P (control output) of GPC-M 0.0 100.0 %
2 Ou.P (control output) of GPC-E1 0.0 100.0 %
3 Ou.P (control output) of GPC-E2 0.0 100.0 %
4 In.A1 (analog input 1) 0.0 100.0 %
5 In.A2 (analog input 2) 0.0 100.0 %
6 In.A3 (analog input 3) 0.0 100.0 %
7 In.PWM1 (PWM input 1) 0.0 100.0 %
8 In.PWM2 (PWM input 2) 0.0 100.0 %
9 In.PWM3 (PWM input 3) 0.0 100.0 %
10 I.VF (line voltage) of GPC-M 0.0 6553.5 V
11 I.VF (line voltage) of GPC-E1 0.0 6553.5 V
12 I.VF (line voltage) of GPC-E2 0.0 6553.5 V
13 Ld.V (load voltage) of GPC-M 0.0 6553.5 V
14 Ld.V (load voltage) of GPC-E1 0.0 6553.5 V
15 Ld.V (load voltage) of GPC-E2 0.0 6553.5 V
16 Ld.V.t (voltage on three-phase load) 0.0 6553.5 V
17 Ld.A (current in load) of GPC-M 0.0 6553.5 A
18 Ld.A (current in load) of GPC-E1 0.0 6553.5 A
19 Ld.A (current in load) of GPC-E2 0.0 6553.5 A
20 Ld.A.t (current on three-phase load) 0.0 6553.5 A
21 Ld.P (power on load) of GPC-M 0.0 6553.5 kW
22 Ld.P (power on load) of GPC-E1 0.0 6553.5 kW
23 Ld.P (power on load) of GPC-E2 0.0 6553.5 kW
24 Ld.P.t (power on three-phase load) 0.0 6553.5 kW
25 Serial line value 0.0 6553.5 -
