gefran GPC - Firing Change Status Set Via Serial

81901A “MSW_GPC-40/600A”_03-2021_ENG_page 115
3.30.5. Firing Change status set via serial
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1921
897 16 bit
SERI-
AL_FC
M
MainMenu → M → Expert → Virtual →
SERIAL_FC_1
R/W
Unsigned
Short
02945 E1
MainMenu → M → Expert → Virtual →
SERIAL_FC_2
4993 E2
MainMenu → M → Expert → Virtual →
SERIAL_FC_3
The parameter sets the Firing Change mode set via serial.
Options: 0 = ZC/BF/HSC mode
1 = PA mode
3.30.6. Firing Change status set via serial
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1145
121 bit
BIT_
SERIAL_
FC_PA_
MODE
M
MainMenu → M → Expert → Bit →
BIT_SERIAL_FC_PA_MODE_1
R/W OFF2169 E1
MainMenu → E1 → Expert → Bit →
BIT_SERIAL_FC_PA_MODE_2
4217 E2
MainMenu → E2 → Expert → Bit →
BIT_SERIAL_FC_PA_MODE_3
The bit sets the Firing Change mode set via serial.
Options: OFF = ZC/BF/HSC mode
ON = PA mode
