3.8.8. Power factor
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1740
716 16 bit CoS.F
M
MainMenu → M → Status → CoS.F_1
R
Float
(####.#)
2764 E1
MainMenu → E1 → Status → CoS.F_2
4812 E2
MainMenu → E2 → Status → CoS.F_3
The parameter shows the power factor of the device M or E1 or E2.
3.8.9. RMS load current
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1777
753 16 bit
01.02.06
Ld.A
M
MainMenu → M → Status → Ld.A_1
R
Float
(####.#)
A2801 01.03.06 E1
MainMenu → E1 → Status → Ld.A_2
4849 01.04.06 E2
MainMenu → E2 → Status → Ld.A_3
The parameter shows the RMS load current input of device M or E1 or E2.
3.8.10. RMS current in three-phase load
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1778 754 16 bit 01.01.02 Ld.A.t Global
MainMenu → Global → Status → Ld.A.t
R
Float
(####.#)
A
The parameter shows the RMS current input of the three-phase load.
3.8.11. Ammeter input digital filter
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1243
219 16 bit
04.08.04
Ft.tA
M
MainMenu → M → Inputs → CT input →
Ft.tA_1
R/W
■
Float
(####.#)
sec. 0.12267 04.11.04 E1
MainMenu → E1 → Inputs → CT input →
Ft.tA_2
4315 04:14:04 E2
MainMenu → E2 → Inputs → CT input →
Ft.tA_3
The parameter sets the time constant value of the digital filter applied to the CT ammeter input of device M or E1 or E2. The filter calcu-
lates the average of the values read in the specified time interval. With 0.0 no filter is applied.
min...max: 0.0...20.0
