81901 “MSW_GPC-40/600A”_03-2021_ENG_page 104
3.25. Software shutdown
The Advanced Power Controller can also be switched off by
a software command.
When the software shutdown function is activated:
• The digital input is only enabled if it is associated with
the software shutdown function.
• Outputs are forced to OFF at shutdown. The exception
is the reference signals rL.4 and rL.6, which are forced
to ON.
• HB alarms are reset.
• The generic alarms AL1...AL8 can be enabled or disa-
bled via the parameter oFF.t.
In addition to the parameters shown below, the following
parameters should also be considered for software shut-
down:
• digital input function dIG.1 / dIG.2 / dIG.3 / dIG.4 (see
paragraph “3.12.4. Digital input function”);
• status (STATUS_W) (see paragraph “3.22.3. Status
(STATUS_W)”);
• digital input status dIG.1 / dIG.2 / dIG.3 / dIG.4 (see
paragraph “3.12.2. Digital input status”).
3.25.1. Software startup/shutdown
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1035
11 bit
12.01.02
BIT_
SOFT-
WARE_
ON_OFF
M
MainMenu → M → Expert →
Bit → IT_SOFTWARE_ON_OFF_1
R/W
■
OFF2059 12.02.02 E1
MainMenu → E1 → Expert →
Bit → IT_SOFTWARE_ON_OFF_2
4107 12.03.02 E2
MainMenu → E2 → Expert →
Bit → IT_SOFTWARE_ON_OFF_3
The bit sets the software startup and shutdown.
Options: OFF = Software on
ON = Software off
3.25.2. Software shutdown modes
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1724 700 16 bit OFF.t Global
MainMenu → Global → Controls → OFF.t
R/W
■
Unsigned
Short
0
The parameter sets the software shutdown mode.
Options:
Index Description
0
Outputs rL.1 - rL.2 - rL.3 - rL.5 = OFF
Outputs rL.4 - rL.6 = ON
Generic alarms AL1...AL8 disabled
1
Outputs rL.1 - rL.2 - rL.3 - rL.5 = OFF
Outputs rL.4 - rL.6 = ON
Generic alarms AL1...AL8 enabled
