gefran GPC - Load Voltage with Output Activated; Voltage on Three-Phase Load; Lower Voltmeter Input Scale Limit; Upper Voltmeter Input Scale Limit

81901 “MSW_GPC-40/600A”_03-2021_ENG_page 28
3.9.3. Load voltage with output activated
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1735
711 16 bit Ld.Von
M
MainMenu → M → Status → Ld.Von_1
R
Float
(####.#)
V2759 E1
MainMenu → E1 → Status → Ld.Von_2
4807 E2
MainMenu → E2 → Status → Ld.Von_3
The parameter shows the voltage on the load when the output is activated.
3.9.4. Voltage on three-phase load
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1776 752 16 bit 01.01.01 Ld.V.t Global
MainMenu → Global → Status → Ld.V.t
R
Float
(####.#)
V
The parameter shows the voltage on the three-phase load.
3.9.5. Lower voltmeter input scale limit
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1463
439 16 bit
04.10.01
L.tVL
M
MainMenu → M → Inputs →
VT load input → L.tVL_1
R
Float
(####.#)
V 0.02487 04.13.01 E1
MainMenu → E1 → Inputs →
VT load input → L.tVL_2
4535 04:16:01 E2
MainMenu → E2 → Inputs →
VT load input → L.tVL_3
The parameter shows the lower limit of the measurement scale used for the TV_LOAD voltage transformer input.
The parameter is present if the VLOAD option exists.
3.9.6. Upper voltmeter input scale limit
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1467
443 16 bit
04.10.02
H.tVL
M
MainMenu → M → Inputs →
VT load input → H.tVL_1
R
Float
(####.#)
V
see
table
2491 04:13:02 E1
MainMenu → E1 → Inputs →
VT load input → H.tVL_2
4539 04:16:02 E2
MainMenu → E2 → Inputs →
VT load input → H.tVL_3
The parameter shows the upper limit of the measurement scale used for the TV_LOAD voltage transformer input.
The parameter is present if the VLOAD option exists.
The upper limit default value depends on the controller model:
GPC model Rated voltage H.tVL
GPC 480 480 Vac 530.0
GPC 600 600 Vac 660.0
GPC 690 690 Vac 760.0
