gefran GPC - Output Control from Serial; LED and Digital Input Control from Serial

81901A “MSW_GPC-40/600A”_03-2021_ENG_page 123
3.34.3. Output control from serial
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1249 225 16 bit 10.01.05 S.Ou Global
MainMenu → Global → Expert →
Virtual → S.Ou
R/W
■
Unsigned
Short
0
The parameter sets the control of outputs from serial. The table shows the correspondence between bits and outputs.
Outputs OUT10 OUT9 OUT8 OUT7 OUT6 OUT5 OUT4 OUT3 OUT2 OUT1
bit 9 8 7 6 5 4 3 2 1 0
min...max: 0...1023
3.34.4. LED and digital input control from serial
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1652 628 16 bit 10.01.06 S.LI Global
MainMenu → Global → Expert →
Virtual → S.LI
R/W
■
Unsigned
Short
0
The parameter sets the control of the instrument’s LEDs and digital inputs from serial. The table shows the correspondence between bits,
digital inputs and LEDs.
Input LED
D4 D3 D2 D1 BUT O3 O2 O1 DI2 DI1 ER RN
bit 11 10 9 8 7 6 5 4 3 2 1 0
min...max: 0...4095
