gefran GPC - Allocation of Physical Outputs

81901 “MSW_GPC-40/600A”_03-2021_ENG_page 88
3.19.5. Allocation of physical outputs
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1631 607 16 bit 06.04.01 out.1 Global
MainMenu → Global → Outputs →
Out1...Out10 → out.1
R/W
■
Unsigned
Short
1
1632 608 16 bit 06.04.02 out.2 Global
MainMenu → Global → Outputs →
Out1...Out10 → out.2
R/W
■
Unsigned
Short
2
1633 609 16 bit 06.04.03 out.3 Global
MainMenu → Global → Outputs →
Out1...Out10 → out.3
R/W
■
Unsigned
Short
3
1635 611 16 bit 06.04.04 out.5 Global
MainMenu → Global → Outputs →
Out1...Out10 → out.5
R/W
■
Unsigned
Short
5
1636 612 16 bit 06.04.05 out.6 Global
MainMenu → Global → Outputs →
Out1...Out10 → out.6
R/W
■
Unsigned
Short
6
1637 613 16 bit 06.04.06 out.7 Global
MainMenu → Global → Outputs →
Out1...Out10 → out.7
R/W
■
Unsigned
Short
7
1638 614 16 bit 06.04.07 out.8 Global
MainMenu → Global → Outputs →
Out1...Out10 → out.8
R/W
■
Unsigned
Short
9
1639 615 16 bit 06.04.08 out.9 Global
MainMenu → Global → Outputs →
Out1...Out10 → out.9
R/W
■
Unsigned
Short
31
1640 616 16 bit 06.04.09 out.10 Global
MainMenu → Global → Outputs →
Out1...Out10 → out.10
R/W
■
Unsigned
Short
31
The parameter sets the allocation of the rL signal to the physical output OUT1...OUT10, corresponding to the parameters out.1...out.10.
Several rL signals can be allocated to the same physical output using the OR and AND logical operators. The allocation is identified by an
index.
out.2 is only available with GPC-E1 present. In the three-phase configuration the status of the physical output OUT1 is copied.
out.3 is only available with GPC-E2 present. In the three-phase configuration the status of the physical output OUT1 is copied.
Options:
Index Allocation
0 Output disabled
1 Output rL.1 GPC-M
2 Output rL.1 GPC-E1
3 Output rL.1 GPC-E2
5 Output rL.2 GPC-M
6 Output rL.2 GPC-E1
7 Output rL.2 GPC-E2
9 Output rL.3 OR rL.5 GPC-M
10 Output rL.3 OR rL.5 GPC-E1
11 Output rL.3 OR rL.5 GPC-E2
13 Output rL.4 AND rL.6 GPC-M
14 Output rL.4 AND rL.6 GPC-E1
15 Output rL.4 AND rL.6 GPC-E2
17 Output (rL.3 OR rL.5) GPC-M...GPC-E2
18 Output (rL.4 AND rL.6) GPC-M...GPC-E2
31 Custom output (for out.9 and out.10 only)
Increasing the +32 index inverts the output status for relay or static/Triac type outputs.
