gefran GPC - Direct Setting of an Absolute or Relative Alarm

81901 “MSW_GPC-40/600A”_03-2021_ENG_page 52
3.13.7. Direct setting of an absolute or relative alarm
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1071
47 bit
BIT_
AL1_
ABS_
REL
M
MainMenu → M → Expert →
Bit → BIT_AL1_ABS_REL_1
R/W
■
OFF2095 E1
MainMenu → E1 → Expert →
Bit → BIT_AL1_ABS_REL_2
4143 E2
MainMenu → E2 → Expert →
Bit → BIT_AL1_ABS_REL_3
1079
55 bit
BIT_
AL2_
ABS_
REL
M
MainMenu → M → Expert →
Bit → BIT_AL2_ABS_REL_1
R/W
■
OFF2103 E1
MainMenu → E1 → Expert →
Bit → BIT_AL2_ABS_REL_2
4151 E2
MainMenu → E2 → Expert →
Bit → BIT_AL2_ABS_REL_3
1061
37 bit
BIT_
AL3_
ABS_
REL
M
MainMenu → M → Expert →
Bit → BIT_AL3_ABS_REL_1
R/W
■
OFF2085 E1
MainMenu → E1 → Expert →
Bit → BIT_AL3_ABS_REL_2
4133 E2
MainMenu → E2 → Expert →
Bit → BIT_AL3_ABS_REL_3
1095
71 bit
BIT_
AL4_
ABS_
REL
M
MainMenu → M → Expert →
Bit → BIT_AL4_ABS_REL_1
R/W
■
OFF2119 E1
MainMenu → E1 → Expert →
Bit → BIT_AL4_ABS_REL_2
4167 E2
MainMenu → E2 → Expert →
Bit → BIT_AL4_ABS_REL_3
The parameter sets the absolute or relative mode for alarms 1, 2, 3 and 4, depending on the address used.
Options: OFF = Absolute alarm
ON = Relative alarm
