3.19.4. Status rL
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1036
12 bit
BIT_
STA-
TUS_
RL1
M
MainMenu → M → Expert →
Bit → BIT_STATUS_RL1_1
R2060 E1
MainMenu → E1 → Expert →
Bit → BIT_STATUS_RL1_2
4108 E2
MainMenu → E2 → Expert →
Bit → BIT_STATUS_RL1_3
1037
13 bit
BIT_
STA-
TUS_
RL2
M
MainMenu → M → Expert →
Bit → BIT_STATUS_RL2_1
R2061 E1
MainMenu → E1 → Expert →
Bit → BIT_STATUS_RL2_2
4109 E2
MainMenu → E2 → Expert →
Bit → BIT_STATUS_RL2_3
1038
14 bit
BIT_
STA-
TUS_
RL3
M
MainMenu → M → Expert →
Bit → BIT_STATUS_RL3_1
R2062 E1
MainMenu → E1 → Expert →
Bit → BIT_STATUS_RL3_2
4110 E2
MainMenu → E2 → Expert →
Bit → BIT_STATUS_RL3_3
1039
15 bit
BIT_
STA-
TUS_
RL4
M
MainMenu → M → Expert →
Bit → BIT_STATUS_RL4_1
R2063 E1
MainMenu → E1 → Expert →
Bit → BIT_STATUS_RL4_2
4111 E2
MainMenu → E2 → Expert →
Bit → BIT_STATUS_RL4_3
1040
16 bit
BIT_
STA-
TUS_
RL5
M
MainMenu → M → Expert →
Bit → BIT_STATUS_RL5_1
R2064 E1
MainMenu → E1 → Expert →
Bit → BIT_STATUS_RL5_2
4112 E2
MainMenu → E2 → Expert →
Bit → BIT_STATUS_RL5_3
1041
17 bit
BIT_
STA-
TUS_
RL6
M
MainMenu → M → Expert →
Bit → BIT_STATUS_RL6_1
R2065 E1
MainMenu → E1 → Expert →
Bit → BIT_STATUS_RL6_2
4113 E2
MainMenu → E2 → Expert →
Bit → BIT_STATUS_RL6_3
The bit shows the status of the reference signals rL.1...rL.6 of modules GPC-M, GPC-E1, and GPC-E2, depending on the address used.
Options: OFF = Signal off
ON = Signal on
