gefran GPC - ALSTATE Alarm Status for Single-Phase Loads and Phase 1 of Three-Phase Loads; ALSTATE_HB Alarm Status (Phase 2 of Two-Phase;Three-Phase Loads and Phase 3 of Three-Phase Loads); Alarm Status (ALSTATE_IRQ); Alarm Reset

81901A “MSW_GPC-40/600A”_03-2021_ENG_page 71
3.14.17. ALSTATE alarm status for single-phase loads and phase 1 of three-phase loads
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1536
512
AL-
STATE
M
MainMenu → M → Status →
ALSTATE_1
R2560 E1
MainMenu → E1 → Status →
ALSTATE_2
4608 E2
MainMenu → E2 → Status →
ALSTATE_3
The parameter shows the HB ALSTATE Alarm statuss for single-phase loads and phase 1 of three-phase loads. Each bit signals a state
(bit = 0 corresponds to OFF, bit = 1 corresponds to ON).
Options:
bit HB alarm status
4 HB alarm status for ON time
5 HB alarm status for OFF time
6 AL.HB alarm status (with single-phase load) or AL.HB phase 1 Alarm status (with two-phase or three-phase load)
3.14.18. ALSTATE_HB alarm status (phase 2 of two-phase/three-phase loads and phase 3 of
three-phase loads)
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1528 504 16 bit
AL-
STATE_
HB
Global
MainMenu → Global → Status →
ALSTATE_HB
R
The parameter shows the HB ALSTATE_HB alarm status for phase 2 of two-phase or three-phase loads and phase 3 of three-phase
loads. Each bit signals a state (bit = 0 corresponds to OFF, bit = 1 corresponds to ON).
Options:
bit HB alarm status
0 HB phase 2 alarm status for ON time
1 HB phase 2 alarm status for OFF time
2 AL.HB phase 2 alarm status (with two-phase or three-phase load)
3 HB phase 3 alarm status for ON time
4 HB phase 2 alarm status for OFF time
5 AL.HB phase 3 alarm status (with three-phase load)
3.14.19. Alarm status (ALSTATE_IRQ)
See paragraph “3.13.14. Alarm status (ALSTATE_IRQ)”.
3.14.20. HB, SSR_SHORT, NO_VOLTAGE and NO_CURRENT alarm reset
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1129
105 bit
12.01.04
BIT_
RESET_
HB_PF
M
MainMenu → M → Expert →
Bit → BIT_RESET_HB_PF_1
R/W2153 12.02.04 E1
MainMenu → E1 → Expert →
Bit → BIT_RESET_HB_PF_2
4201 12.03.04 E2
MainMenu → E2 → Expert →
Bit → BIT_RESET_HB_PF_3
The bit sets the reset for HB, SSR_SHORT, NO_VOLTAGE and NO_CURRENT alarms.
Options: OFF = No action
ON = Reset HB, SSR_SHORT, NO_VOLTAGE and NO_CURRENT alarms
