gefran GPC - Generic Alarm Reference Variable Selection

81901 “MSW_GPC-40/600A”_03-2021_ENG_page 44
3.13.2. Generic alarm reference variable selection
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1239
215 16 bit
05.01.02
A1.r
M
MainMenu → M → Alarms →
AL1...AL8 alarms → AL1 → A1.r_1
R/W
■
Unsigned
Short
182263 05.02.02 E1
MainMenu → E1 → Alarms →
AL1...AL8 alarms → AL1 → A1.r_2
4311 05.03.02 E2
MainMenu → E2 → Alarms →
AL1...AL8 alarms → AL1 → A1.r_3
1240
216 16 bit
05.01.03
A2.r
M
MainMenu → M → Alarms →
AL1...AL8 alarms → AL2 → A2.r_1
R/W
■
Unsigned
Short
182264 05.02.03 E1
MainMenu → E1 → Alarms →
AL1...AL8 alarms → AL2 → A2.r_2
4312 05.03.03 E2
MainMenu → E2 → Alarms →
AL1...AL8 alarms → AL2 → A2.r_3
1241
217 16 bit
05.01.04
A3.r
M
MainMenu → M → Alarms →
AL1...AL8 alarms → AL3 → A3.r_1
R/W
■
Unsigned
Short
172265 05.02.04 E1
MainMenu → E1 → Alarms →
AL1...AL8 alarms → AL3 → A3.r_2
4313 05.03.04 E2
MainMenu → E2 → Alarms →
AL1...AL8 alarms → AL3 → A3.r_3
1242
218 16 bit
05.01.05
A4.r
M
MainMenu → M → Alarms →
AL1...AL8 alarms → AL4 → A4.r_1
R/W
■
Unsigned
Short
182266 05.02.05 E1
MainMenu → E1 → Alarms →
AL1...AL8 alarms → AL4 → A4.r_2
4314 05.03.05 E2
MainMenu → E2 → Alarms →
AL1...AL8 alarms → AL4 → A4.r_3
1226
202 16 bit
05.01.06
A5.r
M
MainMenu → M → Alarms →
AL1...AL8 alarms → AL5 → A5.r_1
R/W
■
Unsigned
Short
182250 05.02.06 E1
MainMenu → E1 → Alarms →
AL1...AL8 alarms → AL5 → A5.r_2
4298 05.03.06 E2
MainMenu → E2 → Alarms →
AL1...AL8 alarms → AL5 → A5.r_3
1227
203 16 bit
05.01.07
A6.r
M
MainMenu → M → Alarms →
AL1...AL8 alarms → AL6 → A6.r_1
R/W
■
Unsigned
Short
182251 05.02.07 E1
MainMenu → E1 → Alarms →
AL1...AL8 alarms → AL6 → A6.r_2
4299 05.03.07 E2
MainMenu → E2 → Alarms →
AL1...AL8 alarms → AL6 → A6.r_3
1228
204 16 bit
05.01.08
A7.r
M
MainMenu → M → Alarms →
AL1...AL8 alarms → AL7 → A7.r_1
R/W
■
Unsigned
Short
172252 05.02.08 E1
MainMenu → E1 → Alarms →
AL1...AL8 alarms → AL7 → A7.r_2
4300 05.03.08 E2
MainMenu
→ E2 → Alarms →
AL1...AL8 alarms → AL7 → A7.r_3
1229
205 16 bit
05.01.09
A8.r
M
MainMenu → M → Alarms →
AL1...AL8 alarms → AL8 → A8.r_1
R/W
■
Unsigned
Short
182253 05.02.09 E1
MainMenu → E1 → Alarms →
AL1...AL8 alarms → AL8 → A8.r_2
4301 05.03.09 E2
MainMenu → E2 → Alarms →
AL1...AL8 alarms → AL8 → A8.r_3
