81901A “MSW_GPC-40/600A”_03-2021_ENG_page 45
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
The parameter sets the reference variable for the generic alarms AL1...AL8 of modules GPC-M, GPC-E1 and GPC-E2. The alarm and
module concerned depend on the address used. The range of valid values and the position of the decimal point for alarm threshold and
hysteresis can vary depending on the reference variable chosen for the alarm.
Options:
Index Variable for comparison
Reference
threshold
Alarm threshold
range
Decimal point
position
9 In.A1: Analog input 1
AL.y
(with y = 1...8)
LS.A1…HS.A1 ###.#
10 In.Pwm1: input PWM 1 0.0…100.0 ###.#
11 In.A2: Analog input 2 LS.A2…HS.A2 ###.#
12 In.A3: Analog input 3 LS.A3…HS.A3 ###.#
13 In.Pwm2: input PWM 2 0.0…100.0 ###.#
14 In.Pwm3: input PWM 3 0.0…100.0 ###.#
15 I.tA_x: instantaneous load current of module x * L.tA_x…H.tA_x * ###.#
16 I.tV_x: instantaneous line voltage of module x * L.tV_x…H.tV_x * ###.#
17 I.on_x: Load current of module x at activated output * L.tA_x…H.tA_x * ###.#
18 I.VF_x: Filtered line voltage of module x * L.tV_x…H.tV_x * ###.#
19 Ld.I_x: load impedance of module x * 0.00…655.35 ####.##
20 In.Ntc.SSR_x: SSR heat sink temperature of module x * 10.0…120.0 ###.#
21 In.Ntc.LINE_x: LINE terminal temperature of module x * 10.0…120.0 ###.#
22 In.Ntc.LOAD_x: LOAD terminal temperature of module x * 10.0…120.0 ###.#
*) x = 1 identifies GPC-M, x = 2 identifies GPC-E1; x = 3 identifies GPC-E2
