gefran GPC - HW and SW Information; Software Version Code; Hardware Configuration Codes

81901A “MSW_GPC-40/600A”_03-2021_ENG_page 125
3.35. HW and SW information
The hardware and software of the Advanced Power Con-
troller can be identified and its functioning checked by
accessing the information registers.
3.35.1. Software version code
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1146 122 16 bit 02.01 UPd Global
MainMenu → Global → Info → UPd
R
Float
(###.##)
The register shows the software version (versione_major.versione_minor).
3.35.2. Hardware configuration codes
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1214 190 16 bit 02.02 C.Hd Global
MainMenu → Global → Info → C.Hd
R
Unsigned
Short
The register shows the output hardware configuration.
Options:
bit Configuration
0 OUTPUT AUX absent
1 OUTPUT AUX relay
2 OUTPUT AUX logic
3 OUTPUT AUX triac 250 Vac 1 A
5 AUX OUTPUT analog 12bit 20mA/10V
14 EXTERNAL CT (for all models: 1PH / 2PH / 3PH)
