3.20.1. Types of analog output
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1889 865 16 bit 06.05.01 tP.AO1 Global
MainMenu → Global →
Outputs → Analog output1 → tP.A01
R/W
■
Unsigned
Short
1
1890 866 16 bit 06.06.01 tP.AO2 Global
MainMenu → Global →
Outputs → Analog output2 → tP.A02
R/W
■
Unsigned
Short
1
1891 867 16 bit 06.07.01 tP.AO3 Global
MainMenu → Global →
Outputs → Analog output3 → tP.A03
R/W
■
Unsigned
Short
1
The parameter sets the type of analog outputs 1, 2 and 3, depending on the address used. Allocation is identified by an index.
Options:
Index Types of analog output
0 Current output 0...20 mA
1 Current output 4...20 mA
2 Voltage output 0...10 V
3 Voltage output 2...10 V
Increasing the index by +16 inverts the output status.
Examples:
Setting value 17 (= 1 + 16) ensures that the minimum output (4 mA) is at the maximum value of the set reference and the maximum output
(20 mA) is at the minimum value of the set reference.
