3.34. Virtual instrument control
The virtual instrument allows the hardware resources of the
device to be set up from the serial line, writing dedicated
configuration parameters instead of using the normal con-
troller processing flow.
Control of the virtual instrument is activated via the param-
eter hd.1.
By setting the S.In e S.Ou parameters, it is possible to
enable the writing of certain variables from the serial line
and impose the value of the inputs and the status of the
outputs.
Alarm thresholds AL1... must be enabled. AL4 when write
operations are continuous and there is no need to keep the
last value in the EEPROM.
Enabling digital input D1 allows the status of this input to
be set, for example to perform MAN/AUTO switching by
writing bit 10 of the SERIAL_LED register.
Similarly, the ON/OFF state of outputs OUT1...OUT10 and
LEDs can be set by writing bits in the SERIAL_IN_OUT
register.
3.34.1. Enabling instrument control via serial
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1215 191 16 bit 10.01.01 hd.1 Global
MainMenu → Global → Controls → hd.1
R/W
■
Unsigned
Short
0
The parameter enables control of the virtual instrument via serial.
Options: 0 = Virtual instrument not enabled
2 = Virtual instrument enabled
3.34.2. Input control from serial
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1248
224 16 bit
10.01.02
S.In
M
MainMenu → Global → Expert →
Virtual → S.In_1
R/W
■
Unsigned
Short
02272 10.01.03 E1
MainMenu → Global → Expert →
Virtual → S.In_2
4320 10.01.04 E2
MainMenu → Global → Expert →
Virtual → S.In_3
The parameter sets the control of inputs from serial. The table shows the correspondence between bits and inputs.
Inputs In.A1 In.A2 In.A3 - - - - AL4 AL3 AL2 AL1
bit 10 9 8 7 6 5 4 3 2 1 0
NOTE: Inputs In.A1, In.A2 and In.A3 are only valid for GPC-M.
min...max: 0...2047
