81901A “MSW_GPC-40/600A”_03-2021_ENG_page 35
3.11.1. Power on load
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1904
880 32 bit
01.02.07
Ld.P
M
MainMenu → M → Status → Ld.P_1
R
Float32
(####.#)
kW2928 01.03.07 E1
MainMenu → E1 → Status → Ld.P_2
4976 01.04.07 E2
MainMenu → E2 → Status → Ld.P_2
The parameter shows the value of the power on the load.
3.11.2. Power on three-phase load
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1906 882 32 bit 01.01.03 Ld.P.t Global
MainMenu → Global → Status → Ld.P.t
R
Float32
(####.#)
kW
The parameter shows the value of the power on the 3-phase load, which is the sum of the loads on the 3 individual phases.
3.11.3. Load impedance
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1773
749 16 bit
01.02.08
Ld.I
M
MainMenu → M → Status → Ld.I_1
R
Float
(####.#)
ohm2797 01.03.08 E1
MainMenu → E1 → Status → Ld.I_2
4845 01.04.08 E2
MainMenu → E2 → Status → Ld.I_3
The parameter shows the load impedance value. The value is calculated by dividing the value of Ld.V by the value of Ld.A .
3.11.4. Three-phase load impedance
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1774 750 16 bit 01.01.04 Ld.I.t Global
MainMenu → Global → Status → Ld.I.t
R
Float
(####.#)
ohm
The parameter shows the impedance value of the three-phase load. The value is calculated by dividing the average value of the three Ld.V
values by the average value of the three Ld.A values.
3.11.5. E1 Energy consumed
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1555
531 32 bit
01.02.09
Ld.E1
M
MainMenu → M → Status → Ld.E1_1
R
■
Unsigned
Int
kWh2579 01.03.09 E1
MainMenu → E1 → Status → Ld.E1_2
4627 01.04.09 E2
MainMenu → E2 → Status → Ld.E1_3
This parameter shows the value of the E1 energy consumed since the meter was switched on or last reset.
