3.35.3. Hardware configuration codes 1
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1532 508 16 bit 02.03 C.Hd1 Global
MainMenu → Global → Info → C.Hd1
R
Unsigned
Short
The register shows the hardware configuration of the controller’s Fieldbuses.
Options:
bit Configuration
2 -
3 FIELDBUS ETH4 (ProfiNet)
4 FIELDBUS ETH8
5 FIELDBUS ETH6
6 FIELDBUS absent
7 FIELDBUS Modbus
8 FIELDBUS Profibus
9 FIELDBUS CanOpen
10 FIELDBUS DeviceNet
11 FIELDBUS Ethernet
12 FIELDBUS Euromap66
13 FIELDBUS ETH3
14 FIELDBUS ETH7 (Ethercat)
15 FIELDBUS ETH1 (Ethernet IP)
3.35.4. Hardware configuration codes 2/3/4
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1567 543 16 bit 02.04 C.Hd2 Global
MainMenu → Global → Info → C.Hd2
R
Unsigned
Short
1216 162 16 bit 02.05 C.Hd3 Global
MainMenu → Global → Info → C.Hd3
R
Unsigned
Short
1217 193 16 bit 02.06 C.Hd4 Global
MainMenu → Global → Info → C.Hd4
R
Unsigned
Short
The register shows the hardware configuration (rating) of GPC-M, GPC-E1 and GPC-E2, according to the chosen address.
Options:
bit Configuration
0 no power
1 40 A
2 60 A
3 100 A
4 150 A
5 200 A
6 250 A
7 300 A
8 400 A
9 500 A
10 600 A
