gefran GPC - Phase Softstart Ramp Restart; Phase Softstart Ramp Status; Phase Softstart Ramp Completion Status

81901A “MSW_GPC-40/600A”_03-2021_ENG_page 111
3.28.5. Phase softstart ramp restart
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1132
108 bit
BIT_
SOFTS-
TART_RE-
START
M
MainMenu → M → Expert → Bit →
BIT_SOFTSTART_RESTART_1
R/W OFF2156 E1
MainMenu → E1 → Expert → Bit →
BIT_SOFTSTART_RESTART_2
4204 E2
MainMenu → E2 → Expert → Bit →
BIT_SOFTSTART_RESTART_3
The bit sets enablement of phase softstart ramp restart.
Options: OFF = No function
ON = Restart enabled
3.28.6. Phase softstart ramp status
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1130
106 bit
M
BIT_
STATUS_
SOFTS-
TART
M
MainMenu → M → Expert → Bit →
BIT_STATUS_SOFTSTART_1
R2154 E1 E1
MainMenu → E1 → Expert → Bit →
BIT_STATUS_SOFTSTART_2
4202 E2 E2
MainMenu → E2 → Expert → Bit →
BIT_STATUS_SOFTSTART_3
The bit shows the status of the phase softstart ramp.
Options: OFF = Ramp not active
ON = Ramp active
3.28.7. Phase softstart ramp completion status
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1131
107 bit
BIT_
STATUS_
SOFT-
START_
END
M
MainMenu → M → Expert → Bit →
BIT_STATUS_SOFTSTART_END_1
R2155 E1
MainMenu → E1 → Expert → Bit →
BIT_STATUS_SOFTSTART_END_2
4203 E2
MainMenu → E2 → Expert → Bit →
BIT_STATUS_SOFTSTART_END_3
The bit shows the completion status of the phase softstart ramp.
Options: OFF = Ramp not ended
ON = Ramp ended
