gefran GPC - HB Alarm Threshold as Function of Power on Load; HB (or TA1-TA2-TA3) or POWER FAULT Alarm Status

81901A “MSW_GPC-40/600A”_03-2021_ENG_page 69
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
The parameter sets the HB calibration when using IR lamps. The following table shows the correspondence between acronym and per-
centage of conduction voltage.
Acronym Voltage
Ir.tV.0 100 % conduction
Ir.tV.1 50 % conduction
Ir.tV.2 30 % conduction
Ir.tV.3 20 % conduction
Ir.tV.4 15 % conduction
Ir.tV.5 10 % conduction
Ir.tV.6 5 % conduction
Ir.tV.7 3 % conduction
Ir.tV.8 2 % conduction
Ir.tV.9 1 % conduction
min...max: 0.0...999.9
For details of HB calibration with IR lamps see paragraph “4.4.3. HB alarm threshold teach-in function”.
3.14.12. HB alarm threshold as function of power on load
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1768
744 16 bit Hb.tr
M
MainMenu → M → Alarms →
HB alarm → Hb.tr_1
R
Float
(####.#)
A2792 E1
MainMenu → E1 → Alarms →
HB alarm → Hb.tr_2
4840 E2
MainMenu → E2 → Alarms →
HB alarm → Hb.tr_3
The parameter shows the HB alarm threshold as a function of the power on the load.
min...max: 0.0...3275.0
3.14.13. HB (OR TA1-TA2-TA3) OR POWER FAULT alarm status
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1050
26 bit
BIT_
STATUS_
HB_OR_
PF
M
MainMenu → M → Expert → Bit →
BIT_STATUS_HB_OR_PF_1
R2074 E1
MainMenu → M → Expert → Bit →
BIT_STATUS_HB_OR_PF_2
4122 E2
MainMenu → M → Expert → Bit →
BIT_STATUS_HB_OR_PF_3
The parameter shows the HB (OR TA1-TA2-TA3) OR POWER_FAULT alarm status.
Options: OFF = Alarm off
ON = Alarm on
