81901A “MSW_GPC-40/600A”_03-2021_ENG_page 47
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
The parameter sets the alarm threshold for generic alarms AL1...AL8 of modules GPC-M, GPC-E1 and GPC-E2. The threshold and mod-
ule concerned depend on the address used. The default values may depend on the controller model.
*) The range of valid values for the threshold and the position of the decimal point may vary according to the reference variable chosen for
the alarm Ax.r (with x = 1...8).
min...max: -999...999 If symmetrical alarm
0...999 If symmetrical and relative alarm
For further information on symmetrical alarms, see paragraph “4.4.1. Generic alarms AL1...AL8”.
Table A
Model Default
480 V 528.0
600 V 658.0
690 V 758.0
Table B
Model Default
40 A 0.4
60 A 0.6
100 A 1.0
150 A 1.5
200 A 2.0
250 A 2.5
300 A 3.0
400 A 4.0
500 A 5.0
600 A 6.0
Table C
Model Default
40 A 44.0
60 A 66.0
100 A 110.0
150 A 165.0
200 A 220.0
250 A 275.0
300 A 330.0
400 A 440.0
500 A 550.0
600 A 660.0
