gefran GPC - Page 69

81901A “MSW_GPC-40/600A”_03-2021_ENG_page 67
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
The parameter sets the HB calibration when using IR lamps. The following table shows the correspondence between acronym and per-
centage of conduction current.
Acronym Current
Ir.tA.0 100 % conduction
Ir.tA.1 50 % conduction
Ir.tA.2 30 % conduction
Ir.tA.3 20 % conduction
Ir.tA.4 15 % conduction
Ir.tA.5 10 % conduction
Ir.tA.6 5 % conduction
Ir.tA.7 3 % conduction
Ir.tA.8 2 % conduction
Ir.tA.9 1 % conduction
min...max: 0.0...3275.0
For details of HB calibration with IR lamps see paragraph “4.4.3. HB alarm threshold teach-in function”.
