CHAPTER 7
135
Gerber Solara ion Web Pages
4/29/10 Rev G
View Satellite Log
The View Satellite Log link displays the Satellite Message Log which records information and
error messages sent from the following components:
Ballast board
Carriage board
Front panel board
Gantry board
Table board
Tip: The Master board messages are displayed in the Message Log. See page Error! Bookmark
not defined. for more information.
The numbers in the brackets to the left of the message indicate the time the message was logged
since the printer was powered on. The time is displayed in
[hours : minutes : seconds : milliseconds].
The Satellite Log can contain up to 500 bytes of text messages. When the log becomes full, the
newest message replaces the oldest message in the log.
