General requirements
The following sections provide an overview of Gerber Solara ion size, weight, and
recommended operating conditions.
Size and weight
You must have enough room to maneuver the packed Gerber Solara ion to its final location
where you can unpack and assemble it.
CAUTION: The Gerber Solara ion is packaged in several crate assemblies that vary
based on the printer’s configuration. The customer is responsible for providing
appropriate equipment (fork lift or palette jack with extended forks) for unloading
and moving the system into place. If a loading dock is not available, you must have
a forklift capable of unloading the system from the back of the delivery truck. The
fork lift must be able to lift 1,100 lbs. (499kg) and needs extended forks which are at
least 8 feet (2.5m). If this equipment is not available or the system requires
movement to an upper floor, riggers or special equipment will be required. This is
the responsibility of the customer.
Crate # Flatbed-only Configuration Crated Size Crated Weight
1 140" long x 35.25" wide x 78" high (356cm cm x 89cm x 198cm) 1,043 lbs. (473kg)
2 119" long x 35.25" wide x 52" high (302cm x 89cm x 132cm ) 850 lbs. (386kg)
Flatbed-only Configuration Uncrated Size Uncrated Weight
147" long x 104" wide x 52" high (373cm x 264cm x 132cm) ~1,000 lbs. (454kg)
Crate # Roll-to-Roll Configuration Crated Size Crated Weight
1 140" long x 35.25" wide x 78" high (356cm cm x 89cm x 198cm) 1,100 lbs. (499kg)
2 119" long x 35.25" wide x 52" high (302cm x 89cm x 132cm ) 850 lbs. (386kg)
3 75.5" long x 35.25" wide x 32" high (192cm x 89cm x 81cm) 280 lbs. (127kg)
Roll-to-Roll Configuration Uncrated Size Uncrated Weight
148" long x 104" wide x 52" high (376cm x 264cm x 132cm) ~1,000 lbs. (454kg)
