CHAPTER 5
71
Printing Jobs on the GERBER SOLARA ION
4/29/10 Rev G
8 As the job prints, the job status line scrolls to display additional job information and
the progress bar updates.
Every 10 minutes while the printer is on, the Gerber Solara ion clears the printhead
nozzles by spitting ink in the waste ink tray. If the printer is actively printing, it pauses
at the end of a swipe, moves carriage to the spitting location and clears the nozzles.
After spitting, printing resumes.
9 After completing the job, the Job Complete message displays, the printheads return to
the park position, the lamps turn off, and the printer beeps.
The screen then displays the
Printer Ready message. When the next job is received, you
will need to press the RUN JOB key to begin printing.
Media feed adjustment on a Roll-to-Roll job
Note: Onyx (or other RIP software) is the only place you should adjust the media feed for Roll-
to-Roll. This procedure explains the adjustment using Onyx; your RIP software procedure may
vary and may use a default overlap value of 10000 rather than 240.
If you experience an overlap when printing in Roll-to-Roll mode, you must decrease the
number in the media feed adjustment box in Onyx RIP software (or other RIP software). For a
gap in Roll-to-Roll, increase the number.
It may also be helpful to add a 1" (25.4mm) top offset to the job in Onyx RIP software. The 1"
leader makes the overlap more consistent. Adjust the top offset in the Onyx’s Change Media
and Placement dialog box under Setup.
Job Complete
To Next Page
