Gerber Solara ion User Manual

CHAPTER 2
25
Product Overview
4/29/10 Rev G
Major sub-menus from the menu system are briefly described below.
Tip: For a graphical representation of the printer's menu structure, refer to the appendix at
the end of this manual.
Status
The Status section of the printer's menu displays the printer's Firmware Version.
Setup
The Setup section of the printer's menu provides access to UV lamp controls as well as
displaying the Network Configuration settings. To change the network settings, you must use
the Gerber Solara ion web pages. See the “Network Settings” on page 129 for detailed
instructions.
 Lamp Delay mode allows the user to
set the UV lamps to remain on for 10 minutes
after completing a job when printing in Flat Bed or single Roll-to-Roll mode.
 Lamp Spec mode is a special UV lamp setting that may be helpful for certain materials
that need extra heat to cure ink. Lamp Spec mode activates the UV lamps at a higher
temperature than normal and warms the material prior to the start of the job.
 Large Field mode improves the print quality of large solid areas of color, especially
light blue or green. Once Large Field is enabled it remains active until disabled by the
operator. Large Field can also be controlled from the System Settings web page. See
page 64 for more information.
 IP Address
 Subnet Mask
 DH
CP (not currently active, for future use)
 MAC Address
Calibration
The Calibration section of the printer's menu provides access to Park Position Cal as well as a
number of Test Jobs.
 Test Jobs
 Nozzle Out Job
 Angled Nozzle Job
 360 Horizontal Align Job
 720 Horizontal Align Job
 Mechanical Align Job
