CHAPTER 4
43
Loading Inks and Materials
4/29/10 Rev G
equipped), which makes use of both the roll material loader bar and the automatic winder unit.
The roll-to-roll configuration uses eight pinch and grit wheels to grip and pull the material
through the printer's roll-to-roll assembly.
When printing, fans under the material create a vacuum to hold the material firmly against the
printer's flat bed or roll-to-roll platen to maintain its position during printing. By choosing
either the FLAT BED or ROLL-TO-ROLL key on the control panel, the correct vacuums are
enabled when pressing the LOAD/UNLOAD key.
