disposed of after one hour of exposure time. Wear safety goggles to protect your
eyes. Dispose of used gloves according to local laws and regulations.
1 From the main control panel press the MENU key. The
Status screen displays.
2 Press the or key until the
Maintenance screen displays.
3 Press ENTER to display the
End of Day Clean screen.
4 Press the or key until the
Inspect Nozzles screen displays.
5 Press ENTER to begin the Inspect Nozzles procedure. The gantry moves to the front of
the printer and the carriage moves into the inspection position. The screen prompts
you to
Lower shelf.
6 Lower the Maintenance Shelf by pushing down in the middle of the shelf. Do not push
on either end of the shelf as it causes the shelf to twist.
7 Using your hand move the sliding UV shield toward the
center of the printer. Wipe any uncured ink off the UV
shield with an all-purpose wipe. Clean any cured ink off
the UV shield using a straight edge razor blade.
8 Wipe any uncured ink off the left and right side plates
with an all-purpose wipe. Clean any cured ink off the
side plates using a straight edge razor blade. The screen
prompts you to
Raise shelf when done. Be sure to complete
steps 9 and 10 below before raising shelf.
End of Day Clean
Lower shelf.
Status
Maintenance
Inspect Nozzles
Sliding UV Shield
