CHAPTER 6
92
Routine Printer Maintenance
4/29/10 Rev G
4 Press the or key until the Clean Heads screen displays.
5 Press ENTER to display the
Choose color screen. Use the or key until the correct
color displays.
6 Press ENTER to select that color. From here follow the normal Clean Heads Procedure
(see procedure starting on page 84).
7 When the
Clean Heads procedure is complete, the system prompts you to
Replace Head
Access Door.
8 After the head access door is installed the gantry moves to the Maintenance Shelf
position and the screen prompts you to
Lower shelf and swab printheads.
9 Lower the Maintenance Shelf by pushing down in the middle of the shelf. Do not push
on either end of the shelf as it causes the shelf to twist.
10 Place 3-5 drops of Daily Maintenance Solution onto a new Anticon-covered swab. See
photo above.
11 Wipe the cleaned printhead from back to front 2 times at a 45 angle, using light
pressure, by holding the swab in the middle of the stick, between the thumb and index
finger as pictured below.
Clean Heads
Magenta
Choose color:
To Next Page
