UCM6510 IP PBX User Manual
Page 118 of 277
PSTN DETECTION
The UCM6510 provides PSTN detection function to help users detect the busy tone, Polarity Reversal and
Current Disconnect by making a call from the PSTN line to another destination. The detecting call will be
answered and up for about 1 minute. Once done, the detecting result will show and can be used for the
UCM6510 settings.
1. Go to UCM6510 web GUI->PBX->Basic/Call Routes->Analog Trunks page.
2. Click to edit the analog trunk created for the FXO port.
3. In the dialog window to edit the analog trunk, go to "Tone Settings" section and click on for
“PSTN Detection”.
Figure 57: UCM6510 FXO Tone Settings
4. Click on "Detect" to start PSTN detection.
Figure 58: UCM6510 PSTN Detection
