Firmware Version 1.0.1.12

UCM6510 IP PBX User Manual

Page 35 of 277

SYSTEM SETTINGS

This section explains configurations for system-wide parameters on the UCM6510. Those parameters

include Network Settings, Firewall, Change Password, LDAP server, HTTP server, Email settings, Time

Settings and NTP Server settings.

NETWORK SETTINGS

After successfully connecting the UCM6510 to the network for the first time, users could log in the web GUI

and go to Settings->Network Settings to configure the network parameters for the device. Select each

tab in web GUI->Settings->Network Settings page to configure LAN/WAN settings, 802.1X and Port

Forwarding.

Note:

To connect the UCM6510 to network, T1/E1/J1 data trunk can also be used, instead of using the

WAN/LAN port. Please see section [DATA TRUNK] to use UCM6510 data trunk to connect the device to

Internet.

BASIC SETTINGS

Please refer to the following tables for basic network configuration parameters on the UCM6510.

Table 5: UCM6510 Network Settings->Basic Settings

Method

Select "Route", "Switch" or "Dual" mode on the network interface of UCM6510. The

default setting is "Route".

 Route

WAN port interface will be used for uplink connection. LAN port interface will be

used to serve as router.

 Switch

WAN port interface will be used for uplink connection. LAN port interface will be

used as bridge for PC connection.

 Dual

Both ports can be used for uplink connection. Users will need assign LAN 1 or

LAN 2 as the default interface in option "Default Interface" and configure
