Grandstream Networks UCM6510 IP PBX User Manual

Firmware Version 1.0.1.12
UCM6510 IP PBX User Manual
Page 245 of 277
Figure 120: Parking Lot Status
Table 81: Parking Lot Status
Caller ID
Display the caller ID who parks the call.
Channel
Display channel for the call park.
Extension
Display the parking lot number where the call is parked/retrieved.
Timeout
Display timeout (in seconds) for the parked call. The status page will
dynamically update this timer from 120 seconds (default) to 0. When the timer
reaches 0, the caller who parks the call will be called back.
Other operations are also available in parking lot status section:
 Click on "Parking Lot", the web page will redirect to feature codes page which can also be accessed
via web GUI->PBX->Internal Options->Feature Codes.
 Click on to refresh the parking lot status.
 Click on [ + ] to expand the parking lot details.
 Click on [ - ] to hide the parking details.
SYSTEM STATUS
The UCM6510 system status can be accessed via web GUI->Status->System Status, which displays the
following system information.
 General
 Network
 Storage Usage
 Resource Usage
GENERAL
Under web GUI->Status->System Status->General, users could check the hardware and software
information for the UCM6510. Please see details in the following table.
