Grandstream Networks UCM6510 IP PBX User Manual

Firmware Version 1.0.1.12
UCM6510 IP PBX User Manual
Page 41 of 277
Figure 11: UCM6510 Using 802.1X EAP-MD5
The following table shows the configuration parameters for 802.1X on UCM6510. Identity and MD5
password are required for authentication, which should be provided by the network administrator obtained
from the RADIUS server. If “EAP-TLS” or “EAP-PEAPv0/MSCHAPv2” is used as the 802.1X mode, users
will also need upload 802.1X CA Certificate and 802.1X Client Certificate, which should be also generated
from the RADIUS server.
Table 6: UCM6510 Network Settings->802.1X
802.1X Mode
Select 802.1X mode. The default setting is "Disable". The supported 802.1X mode
are:
 EAP-MD5
 EAP-TLS
 EAP-PEAPv0/MSCHAPv2
Identity
Enter 802.1X mode identity information.
MD5 Password
Enter 802.1X mode MD5 password information.
802.1X CA Certificate
Select 802.1X certificate from local PC and then upload.
802.1X Client
Certificate
Select 802.1X client certificate from local PC and then upload.
STATIC ROUTES
A static route is a pre-determined path that the network traffic travels to reach a specific host or network.
On the UCM6510, the static route function allows the device to use manually configured routes, rather than
dynamically assigned routes or default gateway configured in the UCM6510 web GUI->Network
