Grandstream Networks UCM6510 IP PBX User Manual

Firmware Version 1.0.1.12
UCM6510 IP PBX User Manual
Page 29 of 277
time.
 Hardware Testing
Select "Test SVIP" to perform SVIP test on the device. This is mainly for
factory testing purpose which verifies the hardware connection inside the
device. The diagnostic result displays on the LCD after the test is done.
Web Info
 Protocol: Web access protocol. HTTP or HTTPS. By default it's HTTPS
 Port: Web access port number. By default it's 8089
USE THE LED INDICATORS
The UCM6510 has LED indicators in the front to display connection status. The following table shows the
status definitions.
Table 4: UCM6510 LED INDICATORS
LED Indicator
LED Status
Power 1/Power 2
PoE
LAN
WAN
USB
SD
Phone 1 /Phone 2 (FXS)
Line 1/Line 2 FXO
Solid: Connected
Fast Blinking: Data Transferring
Slow Blinking: Trying to connect
OFF: Not Connected
T1/E1/J1
Solid: Connected and working
Fast Blinking (0.5s on/0.5s off): No cable is
connected; or connected but the link is not
working at all.
Slow Blinking (1s on/1s off): Connected but
the link is only working one-way
