Figure 47: Device List in Zero Config

In this web page, users can also click on “Reset All Extensions” to reset the extensions of all the devices.

SAMPLE APPLICATION

Assuming in a small business office where there are 8 GXP2140 phones used by customer support and 1

GXV3275 phone used by customer support supervisor. 3 of the 8 customer support members speak

Spanish and the rest speak English. We could deploy the following configurations to provisioning the office

phones for the customer support team.

1. Go to web GUI->PBX->Zero Config->Auto Provision Settings, select “Enable Zero Config”.

2. Go to web GUI->PBX->Zero Config->Global Policy, configure Date Format, Time Format and

Firmware Source as follows.

Default Chapter3
