Grandstream Networks UCM6510 IP PBX User Manual

Firmware Version 1.0.1.12
UCM6510 IP PBX User Manual
Page 78 of 277
SSH access of the device.
Syslog
Syslog Server
Configure the URL/IP address for the syslog server.
Syslog Level
Select the level of logging for syslog.
Send SIP Log
Configure whether the SIP log will be included in the syslog message.
Table 24: Global Policy Parameters: Network Settings
Basic Settings
IP Address
Configure how the SIP end device shall obtain the IP address. DHCP or
PPPoE can be selected.
 DHCP
Once selected, users can specify the Host Name (option 12) of the
SIP end device as DHCP client, and Vendor Class ID (option 60) used
by the client and server to exchange vendor class ID information.
 PPPoE
Once selected, users need specify the Account ID, Password and
Service Name for PPPoE.
Advanced Setting
Layer 3 QoS
Define the Layer 3 QoS parameter. This value is used for IP Precedence,
Diff-Serv or MPLS. Valid range is 0-63.
Layer 2 QoS Tag
Assign the VLAN Tag of the Layer 2 QoS packets. Valid range is 0 -4095.
Layer 2 QoS Priority Value
Assign the priority value of the Layer 2 QoS packets. Valid range is 0-7.
STUN Server
Configure the IP address or Domain name of the STUN server. Only
non-symmetric NAT routers work with STUN.
Keep Alive Interval
Specify how often the phone will send a blank UDP packet to the SIP
server in order to keep the "ping hole" on the NAT router to open. Valid
range is 10-160.
Table 25: Global Policy Parameters: Customization
Wallpaper
Screen Resolution 1024 x 600
Check this option if the SIP end device shall use 1024 x 600 resolution for
the LCD screen wallpaper.
 Source
Configure the location where wallpapers are stored.
 File
If "URL" is selected as source, specify the URL of the wallpaper file. If
"Local UCM Server" is selected as source, click to upload wallpaper
file to the UCM6510.
