UCM6510 IP PBX User Manual
Page 252 of 277
Table 84: CDR Filter Criteria
Inbound calls
Inbound calls are calls originated from a non-internal source (like a VoIP trunk) and
sent to an internal extension.
Outbound calls
Outbound calls are calls sent to a non-internal source (like a VoIP trunk) from an
internal extension.
Internal calls
Internal calls are calls from one internal extension to another extension, which are not
sent over a trunk.
External calls
External calls are calls sent from one trunk to another trunk, which are not sent to any
internal extension.
Caller Number
Enter the caller number to be filtered in the CDR report.
Caller Name
Enter the caller name to be filtered in the CDR report.
From Date
Specify "From" date and time to be filtered for the CDR report. Click on the field and
the calendar will show for users to select the exact date and time.
To Date
Specify "To" date and time to be filtered for the CDR report. Click on the field and the
calendar will show for users to select the exact date and time.
The call report will display as the following figure shows.
Figure 131: Call Report
Users could perform the following operations on the call report.
 Sort
Click on the header of the column to sort by this category. For example, clicking on "Start Time" will
sort the report according to start time. Clicking on "Start Time" again will reverse the order.
 Download Records
Click on to download the records filtered out or to
