Firmware Version 1.0.1.12

UCM6510 IP PBX User Manual

Page 255 of 277

There are some other possible values, but these values are almost the application name which are used

by the dialplan.

IAX2/NUM-XXXXXXX: it means this is an IAX call.

Local/@from-internal-XXXXX: it is used internally to do some special feature procedure. We can simply

ignore it.

Hangup: the call is hung up from the dialplan. This indicates there are some errors or it has run into

abnormal cases.

Playback: play some prompts to you, such as 183 response or run into an IVR.

ReadExten: collect numbers from user. It may occur when you input PIN codes or run into DISA

STATISTICS

CDR Statistics is an additional feature on the UCM6510 which provides users a visual overview of the call

report across the time frame. Users can filter with different criteria to generate the statistics chart.

Figure 137: CDR Statistics

Table 85: CDR Statistics Filter Criteria

Trunk Type

Select one of the following trunk type.

 All

 SIP Calls

 PSTN Calls

Call Type

Select one or more in the following checkboxes.

 Inbound calls

 Outbound calls

 Internal calls

 External calls

 All calls

Time Range

 By month (of the selected year).

 By week (of the selected year).
