Grandstream Networks UCM6510 IP PBX User Manual

Firmware Version 1.0.1.12
UCM6510 IP PBX User Manual
Page 146 of 277
Host Name
Configure the IP address or URL for the VoIP provider server of the trunk.
Keep Trunk CID
When enabled, it can avoid overridden by extension's CID if the extension
has CID configured. The default setting is enabled.
Caller ID
Configure the Caller ID. This is the number that the trunk will try to use
when making outbound calls. For some providers, it might not be possible
to set the CallerID with this option and this option will be ignored.
When making outgoing calls, the following rules are used to determine
which CallerID will be used if they exist:
 The CallerID configured for the extension will be looked up first.
 If no CallerID configured for the extension, the CallerID configured for
the trunk will be used.
 If the above two are missing, the "Global Outbound CID" defined in
web GUI->PBX->Internal Options->General will be used.
CallerID Name
Configure the name of the caller to be displayed when the extension has
no CallerID Name configured.
Username
Enter the username to register to the trunk from the provider.
Password
Enter the password to register to the trunk from the provider.
Auth ID
This is the authentication ID for the UCM6510 to register to the trunk if
required by the provider. If not specified, the CallerID name will be sued for
authentication.
Codec Preference
Select audio and video codec for the VoIP trunk. The available codecs are:
PCMU, PCMA, GSM, AAL2-G.726-32, G.726, G.722, G.729, G.723, ILBC,
ADPCM, H.264, H.263 and H.263p. In the selected codec list, users can
click on UP or DOWN arrow to adjust the order for the codec priority.
Enable Qualify
If enabled, the UCM6510 will regularly send SIP OPTIONS to the device to
check if the device is still online. The default setting is "No".
Qualify Timeout
When "Enable Qualify" option is set to "Yes", configure the timeout (in ms)
for the Qualify SIP message. If no response is received within the timeout,
the device is considered offline. The default setting is 1000ms.
Qualify Frequency
When "Enable Qualify" option is set to "Yes", configure the interval (in
seconds) of the SIP OPTIONS message sent to the device to check if the
device is still online. The default setting is 60 seconds.
The maximum number of call
lines
Configure the maximum number of concurrent calls allowed over the trunk
at the same time. The default value is 0 meaning no limit.
Fax Detection
Enable to detect Fax signal from the trunk during the call and send the
received Fax to the default Email address in Fax setting page under web
