Firmware Version 1.0.1.12

UCM6510 IP PBX User Manual

Page 242 of 277

Connected but not configured

Connected and idle

Connected and in use

SD Card

SD Card plugged in

SD Card unplugged

USB

USB plugged in

USB unplugged

LAN PoE

PoE is used

PoE is not used

Power 1/2

Power supply is working

Power supply is abnormal

No power supply

LAN/WAN/Heart Beat

Connected

Not connected

Digital Port T1/E1/J1
