287

Figure 285 Configure advanced WDS

4. Configure advanced WDS settings as described in Table 108.

5. Click Apply.

Table 108 Configuration items

Item Descri

tion

Mesh Identifier

Set the mesh ID.

The default mesh identifier of a device depends on its radio mode.

Link Keep Alive Interval Configure the mesh link keep-alive interval.

Link Backhaul Rate Configure the backhaul radio rate.
