ENGINE
- 167 -
CAUTION:
The buffer boss and woodruff key should be
replaced when removed from the crankshaft.
2). Assembling the crankcase
(1) Apply:
• sealant (Quick Gasket)
(to the mating surfaces of both case halves)
(2) Install:
• dowel pins
(3) Fit the left crankcase onto the right case. Tap
lightly on the case with a soft hammer
CAUTION:
Before installing and torque the crankcase
holding bolts, be sure to check whether the
transmission is functioning properly by
manually rotating the shift drum in both
directions.
(4)Tighten:
• crankcase bolts
(follow the proper tightening sequence)
NOTE:
• Tighten the bolts in stages, using a crises
cross pattern.
3、INSTALL
1). Installing the crankshaft
• crankshaft
NOTE:
Hold the connecting rod at the Top Dead
Center (TDC) with one hand while turning the
nut of the installing tool with the other.
Operate the installing tool until the
crankshaft bottoms against the bearing.
