Example c: ø/32 clock source, 32-state write interval (n = 1), on-chip memory
LC: LDC.B #H'FF,BR
LDC.W #H'0700,SR
MOV.W #m,R1
MOV.W #m+1,R2
MOV.W #m+2,R3
BSR SET32
.ALIGN 2 ; Align on even address
SET32: MOV:S.W R1,@H'92:8 ; 2 Bytes, 9 states
BSR WAIT:8 ; 2 Bytes, 9 states
MOV:S.W R2,@H'A2:8
BSR WAIT:8 Total 32 states
MOV:S.W R3,@H'B2:8
RTS
.ALIGN 2 ; Align on even address
WAIT: NOP ; 2 States
XCH R1,R1 ; 4 States
RTS ; 8 States
Note: The stack is assumed to be in on-chip RAM.
Example d: ø/4 clock source, 20-state write interval (n = 5), external memory
LD: LDC.B #H'FF,BR
LDC.W #H'0700,SR ; Set interrupt mask level to 7
CLR.B @H'F8:8 ; Disable wait states
MOV.W #m,R1
MOV.W #m+5,R2
MOV.W #m+10,R3
MOV:S.W R1,@H'92:8 ; 13 States
BRN LD:8 ; 2 Bytes, 7 states
MOV:S.W R2,@H'A2:8
BRN LD:8
MOV:S.W R3,@H'B2:8
Total 20 states
