Hitachi H8/500 Series - Page 219

Figure 10-13 shows this type of contention.
Write cycle: CPU write to lower byte of FRC
T
1 T2 T3
Internal address bus
Internal write signal
FRC clock pulse
ø
FRC N
M
FRC address
Write data
Figure 10-13 FRC Write-Increment Contention
202
