Hitachi H8/500 Series - Page 392

OCRA (H and L)—Output Compare Register A H'FFA4, H'FFA5 FRT 2
Bit 76543210
Initial value 11111111
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Note: Bit functions are the same as for FRT1.
OCRB (H and L)—Output Compare Register B H'FFA6, H'FFA7 FRT 2
Bit 76543210
Initial value 11111111
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Note: Bit functions are the same as for FRT1.
ICR (H and L)—Input Capture Register H'FFA8, H'FFA9 FRT 2
Bit 76543210
Initial value 00000000
Read/Write RRRRRRRR
Note: Bit functions are the same as for FRT1.
TCR—Timer Control Register H'FFB0 FRT 3
Bit 76543210
ICIE OCIEB OCIEA OVIE OEB OEA CKS1 CKS0
Initial value 00000000
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Note: Bit functions are the same as for FRT1.
