TCSR—Timer Control/Status Register H'FFB1 FRT 3
Bit 76543210
ICF OCFB OCFA OVF OLVLB OLVLA IEDG CCLRA
Initial value 00000000
Read/Write R/(W)* R/(W)* R/(W)* R/(W)* R/W R/W R/W R/W
Note: Bit functions are the same as for FRT1.
* Only writing of 0 to clear the flag is enabled.
FRC (H and L)—Free-Running Counter H'FFB2, H'FFB3 FRT 3
Bit 76543210
Initial value 00000000
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Note: Bit functions are the same as for FRT1.
OCRA (H and L)—Output Compare Register A H'FFB4, H'FFB5 FRT 3
Bit 76543210
Initial value 11111111
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Note: Bit functions are the same as for FRT1.
384
